Mustang
Some would call Mustang “entry-level” because of its price. We’ve added features and value that make this model a top performer. Compare feature-for-feature and you’ll see that a Stealth Mustang is a winner. Good looks, rugged construction, and backed by an industry leader!
Our Colors
Polar White
Black
Metallic Charcoal
Pewter
Standard Features
- 2×3 Tube Steel Main Rails on 5w & 6w SA White, Black, Pewter, & Charcoal Color Choice
- 2×5 Tube Steel Main Rails on 7w Seamless Aluminum Flat Top Roof
- 2×6 Tube Steel Main Rails on 8.5w (1) Pair Plastic Flo-Thru Vents
- 24″ O/C Floor C-Channel Crossmembers SA,TA2 Plastic Corner Blocks on Top Trim
- 16″ O/C Floor C-Channel Crossmembers TA3 1-1/2″ Flat Top & Bottom Trim
- 24″ O/C Steel Z-Post Wall Studs ATP Fenders
- 24″ O/C Tube Steel Roof Bows 24″ Slanted Embossed Stoneguard
- 48″ Tongue Length on 5w & 6w 24″ Slant Wedge on 5-6x Models
- 54″ Tongue Length on 7w 30″ Slant Wedge on 7x Models
- 60″ Tongue Length on 8.5w 36″ Slant Wedge on 8.5x Models
- Triple Tube A-frame on 20′ & above 3/4″ Drymax Floor
- 2000# Drop Leg Jack 3.4mm Lauan Interior Walls
- 3500# Spring Axle w/4″ Drop TA2 No Side Door on 5 Wide Models
- 5200# Spring Axle w/4″ Drop TA3 32W x 68H Side Door w/Barlock on 6 & 7 Wide Models
- ST205/75R15 Silver Radial Tires & Wheels TA2 48W x 78H Side Door w/Barlock on 8.5 Wide Models
- ST225/75R15 Silver Radial Tires & Wheels TA3 Aluminum Door Holdback
- Wide Track Axle/s on 7wide – No interior wheel wellsRear Ramp Door w/16″ Flap & Spring Assist
- Electric Brakes w/7-way Plug on TA & 7w SA Zinc Door Hardware
- 2″ Coupler on SA (1) 12V LED Dome Light w/Switch
- 2-5/16 Coupler on TA & 7w SA Models LED Marker Lights
- 4-Way Electrical Plug on SA LED Strip Tailights
- 7-Way Electrical Plug on TA & SAE (4) 5000# Recessed D-Rings on 8.5×14 and Longer
- Frame for Roof Vent Beavertail on 8.5 x 14 and Above
- Painted Tongue/Rear Sill Black DOT/CSA Approved Safety Equipment
- 6″ Barrier Tape Limited 3 Year Structural Warranty
- .024 Exterior Aluminum – Glued with Screwed Seams
Specifications
Scroll to the right to see more trailer sizes
| Mustang SE | 5 X 8 SA | 5 X 10 SA | 5 X 10 TA | 5 X 12 SA | 5 X 12 TA | 6 X 8 SA | 6 X 10 SA | 6 X 10 TA | 6 X 12 SA | 6 X 12 TA | 6 X 14 SA | 6 X 14 TA | 7 X 10 SAE | 7 X 10 TA | 7 X 12 SAE | 7 X 12 TA | 7 X 14 TA | 7 X 16 TA | 7 X 18 TA | 7 X 20 TA | 8.5 X 12 TA2 | 8.5 X 14 TA2 | 8.5 X 16 TA2 | 8.5 X 18 TA2 | 8.5 X 20 TA2 | 8.5 X 22 TA2 | 8.5 X 24 TA3 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Overall Length | 12'-0" | 14'-0" | 14'-0" | 16'-0" | 16'-0" | 12'-0" | 14'-0" | 14'-0" | 16'-0" | 16'-0" | 18'-0" | 18'-0" | 14'-0" | 14'-0" | 16'-0" | 16'-0" | 18'-0" | 20'-0" | 22'-0" | 24'-0" | 17'-0" | 19'-0" | 21'-0" | 23'-0" | 25'-0" | 27'-0" | 29'-0" |
| Overall Width | 80" | 80" | 80" | 80" | 80" | 92" | 92" | 92" | 92" | 92" | 92" | 92" | 102" | 102" | 102" | 102" | 102" | 102" | 102" | 102" | 102" | 102" | 102" | 102" | 102" | 102" | 102" |
| * Overall Height | 6'-8" | 6'-8" | 6'-8" | 6'-8" | 6'-8" | 7'-8" | 7'-8" | 7'-8" | 7'-8" | 7'-9" | 7'-9" | 7'-9" | 7'-10" | 7'-10" | 7'-10" | 7'-10" | 7'-10" | 7'-10" | 7'-11" | 7'-11" | 8'-5" | 8'-5" | 8'-5" | 8'-5" | 8'-5" | 8'-5" | 8'-5" |
| ** Platform Height | 18" | 18" | 18" | 18" | 18" | 18" | 18" | 18" | 18" | 19" | 19" | 19" | 20" | 20" | 20" | 20" | 20" | 20" | 21" | 21" | 21" | 21" | 21" | 21" | 21" | 21" | 21" |
| Interior Height | 5'-0" | 5'-0" | 5'-0" | 5'-0" | 5'-0" | 6'-0" | 6'-0" | 6'-0" | 6'-0" | 6'-0" | 6'-0" | 6'-0" | 6'-0" | 6'-0" | 6'-0" | 6'-0" | 6'-0" | 6'-0" | 6'-0" | 6'-0" | 6'-6" | 6'-6" | 6'-6" | 6'-6" | 6'-6" | 6'-6" | 6'-6" |
| Interior Overall Length | 9'-8" | 11'-8" | 11'-8" | 13'-8" | 13'-8" | 9'-8" | 11'-8" | 11'-8" | 13'-8" | 13'-8" | 15'-8" | 15'-8" | 12'-2" | 12'-2" | 14'-2" | 14'-2" | 16'-2" | 18'-2" | 20'-2" | 22'-2" | 14'-8" | 16'-8" | 18'-8" | 20'-8" | 22'-8" | 24'-8" | 26'-8" |
| Interior Width | 57" | 57" | 57" | 57" | 57" | 69" | 69" | 69" | 69" | 69" | 69" | 69" | 81" | 81" | 81" | 81" | 81" | 81" | 81" | 81" | 96" | 96" | 96" | 96" | 96" | 96" | 96" |
| Between Wheel Wells | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A | 82" | 82" | 82" | 82" | 82" | 82" | 82" |
| Side Door | Optional | Optional | Optional | Optional | Optional | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard | Standard |
| Side Door W x H | N/A | N/A | N/A | N/A | N/A | 32" x 68" | 32" x 68" | 32" x 68" | 32" x 68" | 32" x 68" | 32" x 68" | 32" x 68" | 32" x 68" | 32" x 68" | 32" x 68" | 32" x 68" | 32" x 68" | 32" x 68" | 32" x 68" | 32" x 68" | 32" x 78" | 32" x 78" | 32" x 78" | 32" x 78" | 32" x 78" | 32" x 78" | 32" x 78" |
| Rear Door | Single or Ramp | Single or Ramp | Single or Ramp | Single or Ramp | Single or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Double or Ramp | Ramp | Ramp | Ramp |
| Rear Door W x H | 54" x 56 1/2" | 54" x 56 1/2" | 54" x 56 1/2" | 54" x 56 1/2" | 54" x 56 1/2" | 66" x 68 1/2" | 66" x 68 1/2" | 66" x 68 1/2" | 66" x 68 1/2" | 66" x 68 1/2" | 66" x 68 1/2" | 66" x 68 1/2" | 78" x 68 1/2" | 78" x 68 1/2" | 78" x 68 1/2" | 78" x 68 1/2" | 78" x 68 1/2" | 78" x 68 1/2" | 78" x 68 1/2" | 78" x 68 1/2" | 94" x 74 1/2" | 94" x 74 1/2" | 94" x 74 1/2" | 94" x 74 1/2" | 94" x 74 1/2" | 94" x 74 1/2" | 94" x 74 1/2" |
| Tongue Weight | 90 | 104 | TBD | 119 | TBD | 116 | 129 | 200 | 142 | 212 | 154 | 225 | 165 | 176 | 187 | 218 | 241 | 267 | 293 | 320 | 294 | 312 | 327 | 353 | 380 | 406 | 459 |
| Ball Size | 2" | 2" | 2-5/16" | 2" | 2-5/16" | 2" | 2" | 2-5/16" | 2" | 2-5/16" | 2" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" |
| G.A.W.R. (Each Axle) | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 5200 |
| G.V.W.R. | 2990 | 2990 | 6990 | 2990 | 6990 | 2990 | 2990 | 6990 | 2990 | 6990 | 2990 | 6990 | 3500 | 6990 | 3500 | 6990 | 6990 | 6990 | 6990 | 6990 | 6990 | 6990 | 6990 | 6990 | 6990 | 6990 | 9990 |
| Curb Weight | 750 | 870 | 1090 | 990 | TBD | 970 | 1075 | 1665 | 1180 | 1770 | 1285 | 1875 | 1375 | 1465 | 1555 | 1815 | 2005 | 2225 | 2445 | 2665 | 2450 | 2600 | 2725 | 2945 | 3165 | 3385 | 3825 |
| Average Payload Capacity | 2240 | 2120 | 5900 | 2000 | TBD | 2020 | 1915 | 5325 | 1810 | 5220 | 1705 | 5115 | 2125 | 5525 | 1945 | 5175 | 4985 | 4765 | 4545 | 4325 | 4540 | 4390 | 4265 | 4045 | 3825 | 3605 | 6165 |
| Brakes | None | None | Electric | None | Electric | None | None | Electric | None | Electric | None | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric |
| Axles | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring | 4" Drop Spring |
| Tires | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST205/75R15 LRC | ST225/75R15 LRD |
| Wheels | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod | Silver Mod |
| Frame | 2" x 3" Tube | 2" x 3" Tube | 2" x 4" Tube | 2" x 3" Tube | 2" x 4" Tube | 2" x 3" Tube | 2" x 3" Tube | 2" x 4" Tube | 2" x 3" Tube | 2" x 4" Tube | 2" x 4" Tube | 2" x 4" Tube | 2" x 5" Tube | 2" x 5" Tube | 2" x 5" Tube | 2" x 5" Tube | 2" x 5" Tube | 2" x 5" Tube | 2" x 6" Tube | 2" x 6" Tube | 2" x 6" Tube | 2" x 6" Tube | 2" x 6" Tube | 2" x 6" Tube | 2" x 6" Tube | 2" x 6" Tube | 2" x 6" Tube |
| Floor | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax | 3/4" Drymax |
| Walls | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax | 3/8" Drymax |
| Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling | Open Stud Ceiling |
| Floor Crossmembers | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 24" O/C C-Channel | 16" O/C C-Channel |
| Wall Posts | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post | 24" O/C Z-Post |
| Roof Bows | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube | 24" O/C Tube |
* Note: Overall height does not include roof vents or A/C. Please add 4″ for roof vents & 13″ for A/C’s.
** Note: Platform Height drops 4″ with 48″ beavertail and drops 5″ with 72″ beavertail.
Stealth Enterprises, LLC reserves the right to make changes to product offerings without notice or obligation. Standard equipment, options, specifications, materials, and other items listed on websites and printed materials are accurate at the time of publication. Some photographs may show optional items available at additional cost. Some specifications listed may be estimates. Consult your local authorized Stealth Trailer dealer for the most updated models, specifications, and pricing.
